Radial Blue RoHS ±10% Tolerance high voltage ceramic disc capacitors 2KV 10000PF

گواهی
Good communication. Will buy from again !

—— Mark Kim

Professional & Patient Sales ,fair transaction

—— Penka Kalacheva

Reliable partner, worth being go on cooperation !

—— Rakesh Saini

چت IM آنلاین در حال حاضر

Radial Blue RoHS ±10% Tolerance high voltage ceramic disc capacitors 2KV 10000PF

تصویر بزرگ :  Radial Blue RoHS ±10% Tolerance high voltage ceramic disc capacitors 2KV 10000PF

جزئیات محصول:

Place of Origin: dongguan uchi electronics co.,ltd
نام تجاری: uchi
گواهی: UL VDE SGS KC CQC
Model Number: CT81-2KV-F10-F7.5-103M

پرداخت:

Minimum Order Quantity: 5000PCS
Packaging Details: bulk
Delivery Time: 10 workdays
Payment Terms: T/T, Western Union
Supply Ability: 100000
توضیحات محصول جزئیات
material: Y5P Y5V color: bule
Voltage: 2KV Capacitance: 10000pF
Shape: Thou Hole Lead shape: Radial



Radial Blue RoHS ±10% Tolerance high voltage ceramic disc capacitors 2KV 10000PF



Quick Details



Low dissipation factor of 1.5% at 1 KHZ

High frequency ≥30KHZ

High current ≥3A

High voltage ≥50KVDC or ≥42KVAC

High insulation resistance ≥10000MΩ

Long life ≥10 years



Description


2KV high voltage ceramic disc capacitoris the indispensable electronic component for high pressure or the UHF instruments, machinery, X-ray machine, precision type instrument, medical equipment, aerospace, voltage regulator, electric power equipment, meters, home appliances, electrostatic spray equipment, military equipment, many other products and industrial applications.



Applications


Indispensable components for high pressure or the UHF instruments, machinery, X-ray machine, precision type instrument, medical equipment, aerospace, voltage regulator, electric power equipment, meters, home appliances, electrostatic spray equipment, military equipment, many other products and industrial applications.



Specification

Electrical Ratings






Model CT81-2KV-F10-F7.5-103M Color Dark Blue
Condition of Testing Frequency Temperature Humidity
1KHZ 22℃ 70%

Static C



apacitance

10000 PF

Outline Size



Withstand Voltage ≥3 KV
Capacitance Range 8000~12000 PF
Dissipation ≤2%
Insulation Resistance

≥10000 MΩ

Temperature Characteristics F

Operating Temperature

-25℃~+85℃ Pitch (F) 7.5 +/- 1 mm

Diameter× Thickness

(MAX)

10.5×3.2 mm Diameter of Lead Wire 0.6 +/- 0.05 mm
Length of Encapsulated Lead Wire (MAX) 4.5 +/-1 mm Length of Lead Wire

25 +/- 2 mm
